Sliding gate triangular roller wheel pulley groove sliding door roller wheels

Products Description v groove wheel for sliding doorV-groove caster wheels are designed to guide equipment by rolling on inverted angle iron track. Elevated track minimizes problems caused by floor debris. The relief groove at the base of the "V" equalizes the load on each face of the angle. When not operating on track, the considerable wheel tread on each side of the V-groove allows for use on smooth floors.  Cast iron/Semi-steel wheel offers a strong, resilient, cost effective solution for heavy loads. The hard tread rolls easily and allows high abrasion resistance; Smooth face allows for symmetrical ride. Main Features1)Offers long service life; even in ongoing usage applications. 2)Popular applications include use in Casters and on sliding gates. 3)specifically for use on inverted angle iron track 4)this caster rolls easily on clean, debris free floors and tracks.Applicationsv groove wheel for sliding door is made specifically for use on inverted angle iron track. They can also be used on flat surfaces. Each wheel has a precisely machined 90° V-groove with relief groove which enables load equalization.

Stent size	38mm*68mm
The pitch of the istallation	23mm*55mm
The wheel width	28mm
The wheel diameter	50mm
Bracket thickness	2mm
Bracket material	Cold rolled steel sheet

Company Profile Workshops Contact us Sales Manager : Selina leeEmail: 13292231969@163.comMobile:008613292231969
Add: :FLOOR 1,11 BUILDINGS, NO.ZB-
0001,WEST OF HENGWU CONNECTING
LINE,HENGSHUI CITY

Contact us if you need more details on Sliding Door Roller Wheels. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Sliding Door Wheel、Wheels For Sliding Doors. If these products fail to match your need, please contact us and we would like to provide relevant information.
